AUTO∞
Installation
Example
Click on the image to scan
Scan images automatically
Main Entrance
Building A - Floor 1
30 FPS
AUTO∞
Main Entrance
2 min agonormal
Parking Garage
1 min agowarning
Server Room
3 min agocritical
Reception Area
30 sec agonormal
Usage
import { ImageScanner } from "@/components/ui/image-scanner";export default function MyComponent() {
return (
<div className="w-full max-w-md mx-auto">
<h1 className="text-2xl font-bold mb-8 text-center">Horizontal Scan</h1>
<ImageScanner
image="/path-to-image.png"
scanDirection="radar"
scanColor="emerald"
autoScan={true}
loop
/>
</div>
);
}Props
Image Scanner
| Prop | Type | Default | Description |
|---|---|---|---|
image | string | undefined | URL or path to the image to be scanned. |
alt | string | "Scanning image" | Alternative text for the image. |
scanSpeed | number | 2 | Speed of the scanning animation in seconds. |
scanColor | string | "emerald" | Color theme of the scanning effect. (emerald, blue, purple, amber, red, cyan, pink) |
scanType | string | "default" | Type of scanning visual effect pattern. (default, grid, radar, pulse, wave, matrix) |
className | string | undefined | Additional CSS classes to apply to the container. |
onScanComplete | (results?: ScanResult[]) => void | undefined | Callback function triggered when scanning is complete. |
autoScan | boolean | false | Automatically start scanning when component mounts. |
scanDelay | number | 0 | Delay in seconds before starting the auto scan. |
scanAtScroll | boolean | false | Trigger scan when component is scrolled into view. |
showDataOverlay | boolean | true | Display scanning data overlay with phase information. |
showProgress | boolean | true | Show progress bar during scanning. |
scanIntensity | string | "medium" | Intensity level of the scanning effect. (low, medium, high, extreme) |
showScanResults | boolean | true | Display scan result indicators on the image. |
loop | boolean | false | Enable continuous looping of the scanning effect. |
scanResults | ScanResult[] | undefined | Custom scan results to display (auto-generated if not provided). |
triggerScan | boolean | false | Externally trigger the scanning effect. |
disableClickToScan | boolean | false | Disable click-to-scan functionality. |
